Specification
Models | GL700101 | GL700104 |
LED | ||
Color | Static White | RGBW 4IN1 |
Light Source | High Power LED | High Power RGBW 4IN1 LED |
LED Source Color | W:2700K
W:3000K W:4000K W:5700 W:6500K |
R:619-624nm
G:520-535nm B:460-475nm W:3000K/4000K/5700K |
CRI for White LED | Ra>80 | Ra>80 |
LED QTY | 1pcs | 1pcs |
Performance | ||
Lumen Output |
– |
|
Efficacy |
– |
|
Beam Angle | 12°Narrow
20°Narrow Medium 30°Medium 45°Wide 12*45°Oval |
12°Narrow
20°Narrow Medium 30°Medium 45°Wide 12*45°Oval |
Electrical | ||
Input Voltage | 24VDC | 24VDC |
Power Consumption | 3W | 3W |
Control | ||
Protocols | Light on off
DMX |
DMX(UCS-C) |
Addressing | Manual Addressing with Colordreamer Addressing Tool | |
Pixels | 1Pixel | 1Pixels |
Physical | ||
Housing | Stainless steel with Tempered Glass | |
Finish Color | Silver Anodised | |
Dimensions(LXWxH) | Diameter 74X210mm | |
Dimensions(LXWxH) | Diameter74X210mm | |
Cable Entry | Bottom entry | |
Mounting | Recessed Mounting | |
Accessory | ||
Packing | Update soon | |
Environment | ||
Operating Temperature | -30℃ to +50℃ | |
Storage Temperature | -40℃ to +70℃ | |
Humidity | 0-90% non-condensing | |
IP Rating | Dry, Damp, Wet locations IP66 | |
Certification and Safety | ||
Certification | CE | |
Wrranty | 2Years Limited Warranty from the Date of Manufacture
Contact us if you need extended warranty |
