DMX Pixel Dot – DM60 | Colordreamer

Product:DMX Pixel Dot – DM60

Description:

The Colordreamer DM60 LED Pixel Dot is an exterior mini size Direct-view dot with high output brightness. Clear or diffused lens available for different application. Custom pixel pitch from 100mm to 1000mm.

CONTACT US

Specification

Models	DM601201	DM601203	DM601204
LED
Color	Static White	RGB	RGBW
Light Source	Epistar or CREE LED	Epistar or CREE LED	Epistar or CREE LED
Color	W:3000K W:4000K W:5700K	R:619-624nm G:520-540nm B:460-480nm	R:619-624nm G:520-540nm B:460-480nm W:3000K/4000K/5700K
CRI for White LED	Ra>80	–	Ra>80
LED QTY	12LEDs	12LEDs	6 RGB LEDs+6White LEDs
Performance
Lumen Output	Update soon	Update soon	93lumen/Transparent Flat Lens CREE RGBW(W3000K) 48lumen/Diffused Dome Lens CREE RGBW(W3000K)
Efficacy	Update soon	Update soon	38lumen/W Transparent Flat Lens CREE RGBW(W3000K) 18lumen/W Diffused Dome Lens CREE RGBW(W3000K)
Beam Angle	100°Transparent Flat Lens 110°Diffused Flat Lens
Electrical
Input Voltage	15-24VDC	15-24VDC	15-24VDC
Power Consumption	2.5W	2.5W	2.5W
Control
Protocols	DMX512 Control	DMX512 Control	DMX512 Control
PWM Frequency	2KHz@16-Bit Grayscale	2KHz@16-Bit Grayscale	2KHz@16-Bit Grayscale
Addressing	Manual Addressing with Colordreamer addressing device
Physical
Material	Aluminum 6063 Body with UV Protected Lens
Finish Color	Black or Custom RAL Color
Lens	Transparent Flat Lens/Diffused Flat Lens
Dimensions(LXWxH)	595922.5mm
Cable Entry	Side Entry/Bottom Entry
Mounting	Surface Mounting with Screw
Packing	Package Size 533636cm
Environment
Operating Temperature	-30℃ to +50℃
Storage Temperature	-40℃ to +70℃
Humidity	0-90% non-condensing
IP Rating	Dry, Damp, Wet locations IP67
Certification and Safety
Certification	CE
Warranty	2Years Limited Warranty from the Date of Manufacture Contact us if you need extended warranty
