Product: Liner Video Battern-LM46 DMX RGBW
50mm Pixel Pitch 120LEDs 20Pixels per Meter
Description:
The LX42 DMX Media Bar is a premium, AC line-powered linear LED luminaire engineered to distinguish facades, walls, and architectural borders with concentrated, even radiance. Its ultra-slim, low-profile design (just 42mm wide) integrates a universal input power supply and DMX512 control, facilitating long, continuous runs without the need for external drivers. Featuring a robust IP67 rating and fine pixel pitch, this fixture delivers dynamic color effects and is ideal for both high-end media facades and cove lighting applications.
Direct Mains Operation: Universal input voltage (100-277V AC) with an integrated power supply enables efficient daisy-chaining over long distances.
Integrated Power & Control: Direct 100-277V AC input with a built-in power supply and DMX512 control via a hybrid connector system
Flexible Configuration with CD-MT512: The CD-MT512 DMX/RDM Addressing Tool allows for direct on-device configuration. Users can easily adjust power consumption (wattage) and redefine the pixel count directly from the device, providing ultimate flexibility for various project requirements and power budgets .
Robust Construction: Built with a durable housing, ensuring reliable performance for permanent installations or touring applications.
Flexible Mounting Options: Supports both fixed and adjustable-angle mounting brackets to accommodate various surface types and achieve precise aiming angles.
