LED Blade Static White S10

Product:LED Blade Static White S10

Description:

The Colordreamer W36 LED Washer is a IP66 rated exterior compact linear grazing luminaire with high output brightness.

CONTACT US

Specification

Models	BLADE S05	BLADE S10	BLADE S15	BLADE S20
LED
Color	Static White	Static White	Static White	Static White
Light Source	Mid Power LED	Mid Power LED	Mid Power LED	Mid Power LED
LED Source Color	W:2700K W:3000K W:3500K W:4000K W2700-6500K	W:2700K W:3000K W:3500K W:4000K W2700-6500K	W:2700K W:3000K W:3500K W:4000K W2700-6500K	W:2700K W:3000K W:3500K W:4000K W2700-6500K
CRI for White LED	Ra 90	Ra 90	Ra 90	Ra 90
LED QTY	5LEDs	10LEDs	15LEDs	20LEDs
Performance
Lumen Output	2400lm	2400lm	2400lm	2400lm
Efficacy	100lm/W based at 4000K	100lm/W based at 4000K	100lm/W based at 4000K	100lm/W based at 4000K
Beam Angle	20°Narrow 30°Wide 45°Wide	20°Narrow 30°Wide 45°Wide	20°Narrow 30°Wide 45°Wide	20°Narrow 30°Wide 45°Wide
Electrical
Input Voltage	120-277VAC	120-277VAC	120-277VAC	120-277VAC
Power Consumption	24W	24W	24W	24W
Control
Protocols	On-off/1-10V Dimmable Dali Dimmable/Triac	On-off/1-10V Dimmable Dali Dimmable/Triac	On-off/1-10V Dimmable Dali Dimmable/Triac	On-off/1-10V Dimmable Dali Dimmable/Triac
Physical
Housing	Aluminum 6063 with Tempered Glass	Aluminum 6063 with Tempered Glass	Aluminum 6063 with Tempered Glass	Aluminum 6063 with Tempered Glass
Finish Color	Powder coating, Black/White/Grey Silver or Custom RAL Color	Powder coating, Black/White/Grey Silver or Custom RAL Color	Powder coating, Black/White/Grey Silver or Custom RAL Color	Powder coating, Black/White/Grey Silver or Custom RAL Color
Dimensions(LXWxH)	1514850mm	2844850mm	4174850mm	5504850mm
Length	151mm/284mm 417mm/550mm	151mm/284mm 417mm/550mm	151mm/284mm 417mm/550mm	151mm/284mm 417mm/550mm
Cable Entry	Bottom Entry	Bottom Entry	Bottom Entry	Bottom Entry
Mounting	Insert Mounting	Insert Mounting	Insert Mounting	Insert Mounting
Packing	Update soon	Update soon	Update soon	Update soon
Environment
Operating Temperature	-30℃ to +50℃	-30℃ to +50℃	-30℃ to +50℃	-30℃ to +50℃
Storage Temperature	-40℃ to +70℃	-40℃ to +70℃	-40℃ to +70℃	-40℃ to +70℃
Humidity	0-90% non-condensing	0-90% non-condensing	0-90% non-condensing	0-90% non-condensing
IP Rating	Dry, Damp, Wet locations IP20	Dry, Damp, Wet locations IP20	Dry, Damp, Wet locations IP20	Dry, Damp, Wet locations IP20
Certificate and Safety
Certification	CE	CE	CE	CE
Warranty	2Years Limited Warranty from the Date of Manufacture Contact us if you need extended warranty	2Years Limited Warranty from the Date of Manufacture Contact us if you need extended warranty	2Years Limited Warranty from the Date of Manufacture Contact us if you need extended warranty	2Years Limited Warranty from the Date of Manufacture Contact us if you need extended warranty
