Spot Light Static White 10W On-Off- QB680101

Product: Spot Light Static White 10W On-Off- QB680101

Description:

The strip provides flexibility to fit on any curved surface.

LED is packaged with pure gold wire and large Epistar chips.

IP20 and IP67 Version available

Each strip is equipped with a 3M VHB double-sided adhesive tape.

Field cuttable.

Contant current drive.

50,000 hours

This RGB strip can be dimmed by PWM driver.

Run lengths are limited to 6amps/96Watts according to ETL.

Specification

Models	DN168401	DN168404
LED
Light Source	SMD 5050	SMD 5050
Color	Static White	RGBW (W:2700K W:3000K W:4000K W:6500K)
CRI for White LED	–	Ra>80
LED QTY	84LEDs per meter
Performance
Lumen Output	530lm	750lm
Efficacy	44lm/W
Beam Angle	120°
Electrical
Input Voltage	24VDC	24VDC
Power Consumption	12W per meter	16W per meter
Control
Protocols	DMX512
Addressing	Manual Addressing with Colordreamer addressing device
Pixels	6pixels/m
Pixel Pitch	100mm
Cutting Pitch	100mm
Physical
Material	Silicone	Silicone
Finish Color	Black or White
Dimensions(WxH)	12mm x 21mm	12mm x 21mm
Max.length	5m/roll
Mounting	Silicone Clip	Silicone Clip
Environment
Operating Temperature	-20℃ to +50℃	-20℃ to +50℃
Storage Temperature	-40℃ to +70℃	-40℃ to +70℃
Humidity	0-90% non-condensing	0-90% non-condensing
IP Rating	Outdoor,IP67	Outdoor,IP67
Certification	CE	CE
