LED Strip 2835 - CC1012001 Static White Contant Current Drive

Product:LED Strip 2835 – CC1012001 Static White Contant Current Drive

Description:

The Colordreamer SPI Flex Strip are flexible strips which can be controlled directly using SK6812.The strip provides flexibility to fit on any curved surface.

All strips are supplied in a 5 meter roll as standard.

We have used superior thickened 3OZ copper tracks to reduce the effects of voltage drop.

IP20 and IP67 are available.

CONTACT US

Specification

Models	CC1012001
LED
Light Source	SMD 2835
Color	2200K/2700K/3000K/4000K/6500K
CRI for White LED	CRI>90
LED QTY	120LEDs per meter
LED Spacing	8.33mm
Performance
Lumen Output	1200lm
Efficacy	100lm per watt
Beam Angle	120°
Electrical
Input Voltage	24VDC
Power Consumption	12W per meter
Control
Protocols	Contant Current Drive
Addressing	N/A
Pixels	60pixels/m
Cutting Pitch	50mm
Physical
Material	Copper 3OZ
Housing Color	White
Length	5000mm
Width	10mm
Height	2mm
Mounting	3M VHB Tape for IP20 Silicone Clips for IP67
Environment
Operating Temperature	-20℃ to +60℃
Storage Temperature	-40℃ to +80℃
Humidity	0-90% non-condensing
IP Rating	Indoor,IP20
Certification	CE
